Products

-D ...................

-E ...................

-F ...................

-G...................

4 to 20 mA DC with digital communication (BRAIN protocol)

4 to 20 mA DC with digital communication (HART protocol, refer to GS 01C22T01-00EN)

Digital communication (FOUNDATION Fieldbus protocol, refer to GS 01C22T02-00EN)

Digital communication (PROFIBUS PA protocol, refer to GS 01C22T03-00EN)

M .................

H..................

1 to 100 kPa {100 to 10000 mmH2O} {4 to 400 inH2O} {10 to 1000 mbar}

5 to 500 kPa { 0.05 to 5 kgf/cm2} {20 to 2000 inH2O} {50 to 5000 mbar}

Wetted parts

material*7

[Body]                             [Capsule]                                [Vent plug]

SUSF316 *1                     SUS316L *2                             SUS316 *8

0..............

1..............

2..............

3..............

4..............

5..............

without process connector (Rc1/4 female on the cover flanges)

with Rc1/4 female process connector

with Rc1/2 female process connector

with 1/4 NPT female process connector *5

with 1/2 NPT female process connector *5

without process connector (1/4 NPT female on the cover flanges)

A............

B............

C............

[Maximum working pressure]

SCM435 32 MPa {320 kgf/cm2}

SUS630 32 MPa {320 kgf/cm2}

SUH660 32 MPa {320 kgf/cm2}

-2 .........

-3 .........

-6 .........

-7 .........

-8 .........

-9 .........

Vertical impulse piping type, right side high pressure, process connector upside*3

Vertical impulse piping type, right side high pressure, process connector downside*3

Vertical impulse piping type, left side high pressure, process connector upside*3

Vertical impulse piping type, left side high pressure, process connector downside*3

Horizontal impulse piping type, right side high pressure*4

Horizontal impulse piping type, left side high pressure*4

0........

2........

3........

4........

5........

7........

8........

9........

A........

C........

D........

G1/2 female, one electrical connection

1/2 NPT female, two electrical connections without blind plug

Pg 13.5 female, two electrical connections without blind plug

M20 female, two electrical connections without blind plug

G1/2 female, two electrical connections and a blind plug

1/2 NPT female, two electrical connections and a blind plug

Pg 13.5 female, two electrical connections and a blind plug

M20 female, two electrical connections and a blind plug

G1/2 female, two electrical connections and a SUS316 blind plug

1/2 NPT female, two electrical connections and a SUS316 blind plug

M20 female, two electrical connections and a SUS316 blind plug

D......

E......

N......

Digital indicator

Digital indicator with the range setting switch*6

(None)

A....

B....

J....

C....

D....

K....

N....

SECC Carbon steel                         2-inch pipe mounting (flat type)

SUS304                                        2-inch pipe mounting (flat type)

SUS316                                        2-inch pipe mounting (flat type)

SECC Carbon steel                         2-inch pipe mounting (L type)

SUS304 or SCS13A                         2-inch pipe mounting (L type)

SUS316 or SCS14A                         2-inch pipe mounting (L type) (None)
