Rosemount 2088 pressure transmitter
Transmitter output:4–20 mA Hart
Origin:Singapore Rosemount
Reference accuracy 0.065% of span
The 2088 pressure transmitter is a pressure measuring instrument that measures the pressure of the pipeline by isolating the deformation of the silent film product and converting the pressure into an electrical signal of 4-20mA or other protocols. Gauge pressure transmitter pressure range from -14.7 to 4000psi. Absolute pressure range from 0 to 4000psi.
• Can provide 0.075% high precision
• Lightweight and compact design for cost-effective installation
• Applicable protocols include 4-20 mA HART® and 1-5 Vdc HART low power consumption
• Absolute and gauge pressure ranges up to 276 bar (4000 psi)
• 20:1 range ratio, Rosemount 2088 pressure transmitter products: Proven reliability for gauge and absolute pressure applications • Applicable protocols include 4-20 mA HART® and 1-5 Vdc HART low power consumption
• Configurable LCD displays process variables, range percentages, and diagnostic messages
• Lightweight and compact design for easy installation
• Stainless steel or alloy C-276 liquid connection material options Discover the true value of your equipment with smart wireless THUM™ adapters • Use field intelligence to improve quality, safety, availability and operation and reduce maintenance costs
• Remotely manage devices and monitor health
2088 demlition plan
2088
Pressure transmitter
CODE
Type of measurement
Standard
A
Absolute
G
Gauge
Pressure ranges
Standard
Rosemount 2088G
Rosemount 2088A
(CODE1)
–14.7 to 30 psi (–1.01 to 2.1 bar)
0 to 30 psi (0 to 2.1 bar)
(CODE2)
–14.7 to 150 psi (–1.01 to 10.3 bar)
0 to 150 psi (0 to 10.3 bar)
(CODE3)
–14.7 to 800 psi (–1.01 to 55.2 bar)
0 to 800 psi (0 to 55.2 bar)
(CODE4)
–14.7 to 4,000 psi (–1.01 to 275.8 bar)
0 to 4,000 psi (0 to 275.8 bar)
Transmitter output
S
4–20 mA dc/Digital HART Protocol
N
1–5 Vdc Low Power/Digital HART Protocol
Materials of construction
Process connection
Isolating diaphragm
Fill fluid
22
316L SST
316L SST
Silicone
23
Alloy C-276
Alloy C-276
Silicone
2B
316L SST
316L SST
Inert
Process connection
CODE A
½–14 NPT female
CODE B
DIN 16288 G½ male
CODE C
RC ½ female
CODE D
M20 x 1.5 male
Conduit entry
CODE(1)
½–14 NPT
CODE(2)
M20 x 1.5
CODE(4)
G½
A brief explanation of (the additional options)
Additional options are mainly for some safety verification certificates, such as explosion-proof, dust explosion-proof and protection measures, as well as whether an LCD watch head is required and some national type certification.
